low profile scissor lift

Product Name:

low profile scissor lift

No. :

DJY-4

Product Description:

Technical specification

Lifting capacity :3000kg

Lifting height :1830mm

Min.height :110mm

Overall length for platform:1475-1975

Overall width for platform :360mm

Motor power:2.2 kw

Power supply :220v/380v/425v

Oil pressure: 20 mpa

air supply pressure:6-8bar

Weight : 1045 kg

Packing size:1620x680x340mm/560x450x1150mm

36 units can be loaded into one 20” container

Feature

Ground mounting

4-cylinders structure, 110mm minimum height

Aluminum motor prevents overheat.

24V safety control system

24V height limit switch included optional

Equipment down to the ground 500 mm, the control box signal device alarm, ensured the safety of operator and surrounding

personnel optional.

Platforms extension for lifting long vehicles.

Pneumatic control lock device.

115% dynamic and 150% static loading test passed

CE approved.
